Digital carton printing machine
Update time:2021-04-27
Industrial ink supply system to make sure printing accuracy and working speed


1) Leading edge automatic paper feeding, needle-type light sensor control, stable and fast paper feeding.

2) Our machine can print multiple sheets at the same time to increase productivity.

3)The paper conveying and driving paper is sucked and absorbed throughout the whole process, and the pressure roller is assisted to ensure the paper is flat and the printing effect is better

4)There are both lifting paper holder and telescopic paper holder for easy operation.
Inquire
Contact us
Rroduct description
Related products

1.Why JCTPRINT’S YH2500-8H

Industrial ink supply system to make sure printing accuracy and working speed


1) Whole new automatic industrial ink supply system, visible secondary ink cartridge, negative pressure control, and ink output more stable.

2) Industrial inkjet system configuration-magnetic grid collecting data



Drive system to ensure printing accuracy and quality: equipped with Suction system

1) Leading edge automatic paper feeding, needle-type light sensor control, stable and fast paper feeding.

2) Our machine can print multiple sheets at the same time to increase productivity.

3)The paper conveying and driving paper is sucked and absorbed throughout the whole process, and the pressure roller is assisted to ensure the paper is flat and the printing effect is better

4)There are both lifting paper holder and telescopic paper holder for easy operation.


Single-Pass and Multi-Pass printing can be realized on one machine!

We have both water poof ink and normal ink-they are all water based ink, which is more environmentally friendly.


Specifications of digital carton printing machine

Product specifications

Printing Head

✔Epson Original Micro-piezoelectric
  ✔High precisionPrint Head.Max up to 8   Arrays for 8 Heads
  ✔Print Head to Board gap is 1mm to 2mm.
  ✔Each pass print width 271mm.

Ink

Two types of Water Base ink   ---Waterproof ink and non-waterproof ink

Colour

C M Y K

Speed

Mode

PASS

Printing Speed

Working Speed

High Speed

1PASS

700SQM/h

400 SQM /h

High precision

2PASS

350 SQM /h

200 SQM /h

Maximum Printing Width

2500mm

Print Length Range

≥360mm

Printing mateiral

All kinds of ordinary cardboard,   corrugated paper, honeycomb cardboard.

Media Thickness

1-70mm

Thickness 1-2mm manual feeding; ≥2mm   automatic feeding

Control Mode

P. L. C.System

Print Resolution

2 pass:720*600    1 pass: 360*600

Ink Drying Speed

Dry immediately for medium paper(drying   speed vary depending on other substrate quality)

Software

Printer Manager by YH and RIP System

Working Environment

Room Temperature 10-35 Degrees,Humidity   20-70%

Rated Power& Power Supply

10KW;AC380±10%,50-60HZ,3 phases

Machine Dimension

4750(L)×2220(W)×1730(H)mm,
   Packing Dimension   4800(L)×2220(W)×1730(H)mm

Machine Weight

Net Weight 4500kg, Gross Weight 4800kg
